High Speed Bridge Typ Machining Center

Takumi high-speed portal machining centers

News


Takumi high-speed portal machining centers

more

- Compact design for companies

- Exceptional rigidity, accuracy and dynamic performance are the key features of Takumi's high-speed portal machines


- H-Series achieves exceptional surface quality





Pliening near Munich, Germany, March 2017: Exceptional rigidity, accuracy and dynamic performance are the key features of Takumi's high-speed portal machines. The H series machines operate with outstanding accuracy and achieve an exceptional surface quality thanks to their sophisticated measuring and sensor control systems. Absolute direct measuring systems, internal coolant feed through the high-speed spindle, direct drives on all axes and electronic temperature compensation come as standard. "Despite their relatively low procurement costs, the technical performance characteristics and values of Takumi's H series machines are all top of the range. This excellent price-performance ratio is what makes these machines particularly interesting", said Eugen Fetsch, Product Manager for the Takumi brand.

Fast and accurate: the Takumi H7 and H10 models

Takumi H7

These two machining portals have the shortest travel paths in the H series. The H7 and H10 models focus on the high-speed applications involved in tool-making, mold-making, medical technology, and the aviation and aerospace industries. They are designed to work with exceptional precision to create the optimum surface finish even in the very tightest spaces. The robust and stable portal design and resistance to high temperatures are the cornerstones of the machines' operating excellence.





Takumi H10The designers have made a lasting improvement to load distribution on the spindle head by designing the portal frame as a ladder-type structure. The H7 and H10 machining portals can handle maximum table loads of up to 500 or 800 kilograms. All of Takumi's H series models come equipped with a Heidenhain control system as standard. Together with the Heidenhain components integrated in the machining centers, they make a huge contribution to the accuracy of the result. The control systems allow programming in dialog and in parallel mode. They also have functions for freely programming contours and options for ISO-NC programming.



Sales and service under one roof

Takumi-branded machine tools are sold and supplied directly by HURCO Germany, its subsidiaries in the Netherlands and Poland, and a network of dealers throughout Europe. Service tasks and application technology support are performed on-site by CNC service staff.

About Takumi

Takumi HQ     HURCO HQ


Founded in 1988, Takumi Machinery Company Ltd. is a machine tool manufacturer organized and based in Taiwan that produces vertical machining centers, double column machining centers, and high speed bridge machines. Takumi machines are equipped with industry standard controls from manufacturers such as Fanuc, Mitsubishi, Heidenhain and Siemens: www.takumi.com.tw/en

Contact:
HURCO GmbH, Imke Blohm, Gewerbestraße 5 a, 85652 Pliening, Germany www.hurco.de.
Phone +49 89 905094 28, Fax: +49 89 905094 90, iblohm@hurco.de
For films and case studies, go to the HURCO Youtube channel

close

Modelle

H7 / H10

H7 / H10

Compact Design

Travels X/Y/Z (mm)up to 1.020 x 700 x 500
Dimensions (mm)up to 1.050 x 700
Max. Load (kg)up to 800

more info

Modelle

G700 / G1000

G700 / G1000

Optimal for Graphit-processing

Travels X/Y/Z (mm)up to 1.020 x 700 x 500
Rapid Traverse (m/min)up to 32/32/32
Max. Load (kg)up to 800

more info

Modelle

H12 / H13 / H16

H12 / H13 / H16

Universal and dynamic

Travels X/Y/Z (mm)up to 1.600 x 1.300 x 900
Dimensions (mm)up to 1.900 x 1.300
Max. Load (kg)up to 6.000

more info

Modelle

H22 / H32

H22 / H32

For great demands

Travels X/Y/Z (mm)up to 3.200 x 2.250 x 950
Dimensions (mm)up to 3.320 x 2.100
Max. Load (kg)up to 8.500

more info

Modelle

U 800

U 800

5-axis machining in compact Gantry construction

Travels X/Y/Z (mm)up to 800 x 1.100 x 750
Dimensions (mm)up to 3.980 x 6.160
Max. Load (kg)up to 1.100

more info



Heidenhain Control iTNC 530 - Titel

Heidenhain

Control iTNC 530

more

Standard



Opional

>Conversational programming >DXF converter
>ISO NC programming >CAD viewer
>FK free contour programming >Adaptive Feed Control (AFC)
>Extended milling and drilling cycles >Dynamic Collision Monitoring (DCM)
>Touch probe cycles >4th and 5th axis
>Parallel operation >Heidenhain-DNC

>Integrated help system >Remote Desktop Manager
>Program verification graphics  >Extended Tool Management
>1024 Block Look Ahead >Dynamic Precision
>0,5 ms Block Processing Time >Dynamic Efficiency
>≥21 Gigabyte Data Storage >
>≥2GB RAM
>15,1” LCD Display
>Least Input Increment 0,0001mm, 0,0001°
>2x Gigabit Ethernet adapter
>4x USB port
>RS-232-C & RS-422 port
>Extended data interface for remote control
close

Outstanding Surface finish - Titel

Outstanding Surface finish


Precision and Throughput

more

>World-class performance for die & mold, aerospace and other high speed applications
>Extremely rigid and thermally stable double-column design
>Designed for parts that require outstanding speed, accuracy and surface finish
>Close proximity of spindle to bridge casting reduces overhang
>Ladder design of bridge provides greater support for the head casting
>Swiveling control panel for optimal floor space utilization

>Extra-wide door openings, for easier loading and unloading
>Large windows, for optimal visibility
>Robust, precision machined castings
>Roller-type rails on all axes for added rigidity
>Integrated washdown and chip management system
>Direct-coupled ballscrews, for increased accuracy
>Absolute linear encoders for fast start-up
>Inline high-speed spindles
